philip FM20 LCD COMPLETE PART M2703‑64503 PN 453564150521

Philip FM20 LCD COMPLETE PART M2703‑64503 PN:453564150521

1. OEM Part Numbers & Compatibility

• OEM Display Assembly Part Numbers:
  • Standard non-touch: M2703‑64503
  • Capacitive touchscreen version: 453564150521

• Compatible Monitors: Philip Avalon FM20, FM30 Fetal Monitors
• Type: 6.5-inch TFT Color LCD Display Module, foldable/tiltable mount, wide‑viewing angle design

2. Core Display Specifications

• Screen Size: 6.5 inches (diagonal, 16.51 cm), 4:3 standard medical aspect ratio
• Resolution: 640 × 480 (VGA), pixel pitch ~0.21 mm
• Brightness: 300 cd/m² (typical), high‑brightness for clinical ward lighting
• Contrast Ratio: 400:1 (typical)
• Color Depth: 16.7M colors (8‑bit), clear waveform/numeric display
• Backlight: White LED (W‑LED) backlight (low power, long lifespan; legacy units use CCFL)
• Viewing Angle: Horizontal ≥160°, Vertical ≥140° (contrast >10:1)
• Response Time: ≤25 ms (GtG), suitable for real‑time monitoring waveform display

3. Mechanical & Interface Parameters

• Physical Dimensions (Module): Approx. 155 × 120 × 12 mm (W × H × D)
• Weight: Approx. 0.45 kg
• Connectors: LVDS video signal interface + capacitive touch control interface (optional), flat‑flex cable direct‑connect to mainboard
• Power Supply: Host‑powered, DC 5V / 12V, typical power consumption ~6W
• Mounting: 0–90° fold/tilt adjustment; direct replacement without upper‑case disassembly; no post‑replacement safety calibration required

4. Environmental & Reliability

• Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Storage Temperature: -20°C to 60°C (-4°F to 144°F)
• Relative Humidity: ≤95% RH (non‑condensing)
• Protection: Medical‑grade dust‑proof, splash‑resistant; compatible with clinical disinfection cleaning

5. Functional Features

• Auto screen layout adaptation (single/twin/triplet, uterine contraction, maternal parameters)
• Large font/waveform display, full‑screen parameter zoom support
• Adjustable backlight brightness, low‑power energy‑saving mode
